TrolMaster modules and sensors all come complete with a RJ12 16ft cable, Y-splitter and RJ12 4 ft cable to connect to the Hydro-x. When connecting modules that are farther apart, you can use the Extension cable set ECS-1. The ECS-1 comes complete with another 16ft cable, Y-splitter and 4 ft cable. FEATURES: Plug & Play

Read more less

The SPH-1 Splitter Hub from TrolMaster makes installation of our controllers as easy as plugging in a phone cable. The SPH-1 hub uses a single RJ12 cable input jack, and provides (8) individual RJ12 output jacks that can be connected to various TrolMaster sensors, adapters and device modules. Using the SPH-1 allows for a "clean" installation and eliminates the need for daisy-chain Y-splitters to be used to interconnect multiple modules or sensors.  The SPH-1 is also a powered hub, meaning that it will boost the signals passing through the SPH-1 allowing more modules, sensors and light adapters to be connected to the TrolMaster controllers. By using the SPH-1, an almost unlimited number of LED / HID lights can be controlled using a single TrolMaster controller. The SPH-1 comes complete with the SPH-1 hub, a 16 foot RJ12 cable and the 12vdc power supply.  The SPH-1 can be located in a central location with a single RJ12 cable connecting it to the main controller. From the SPH-1 hub, the individual RJ12 jacks can be connected to each of the sensors, device modules, or lighting adapters. NOTE: If you are using the SPH-1 to interconnect your lighting systems together back to a single LMA adapter (except for LMA-T and ThinkGrow light system), DO NOT connect the 12 volt dc power supply to the SPH-1. FEATURES: LED indicator  Plug & Play

Read more less

The ECS-2 Extension Cable Set is designed to connect Hydro-X to most LED drivers with a pigtail wiring. The ECS-2 comes with a 16 ft RJ12 cable, a Y-splitter and a special 4 ft RJ12 to Female Barrel Cable. Simply connect the two wires from your LED driver to the terminal block, each of the lights being controlled are wired in a “daisy-chain” configuration back to the Hydro-X LMA adapter. FEATURES: Plug & Play

Read more less

The ECS-5 provides a 5/8” diameter connector for some of Fluence brands newer LED fixtures using PushLock Waterproof Connectors for interconnecting. Like the other ECS kits, the ECS-5 comes with a 16ft RJ12 cable, a T-splitter and a special 4 ft RJ12 / PushLock Waterproof Connector cable. FEATURES: Seamless Connection Plug & Play

Read more less

The ECS-3 provides a 5/8” diameter connector for some of Fluence brands LED fixtures using Threaded Waterproof  Connectors for interconnecting. Like the other ECS kits, the ECS-3 comes with a 16ft RJ12 cable, a T-splitter and a special 4 ft RJ12 / Threaded Waterproof  Connector cable. FEATURES: Plug & Play

Read more less

The AMP-2 module connects the Aqua-X (NFS-1) to a set of precision pH / EC & temperature probes to constantly measure the pH / EC & temperature of the water being sampled. The AMP-2 works with the TrolMaster PCT-1&2 and the PPH-1&2 probes. Once connected to the Aqua-X, the AMP-2 will display the sensor data on the Aqua-x and on the APP. The minimum and maximum “limits” can be set on the Aqua-x providing 24/7 notification of pH / EC or temperatures that are out of limits. FEATURES:  Simpe-to-Use DIN Type Bracket for Easy Installation  BNC Terminal (left) allows Direct Connection to pH Sensor  Mini DIN Terminal (right) allows Direct Connection to EC/Temp Sensor  Mini DIN Terminal (middle) allows Direct Connection to Aqua-X Controller

Read more less

The AMP-3 Sensor Board can be used as a bridge between the sensors (pH Sensor & EC/Temp Sensor) and the Aqua-X Pro/Tent-X Controller. It is specially designed for the Aqua-X and Tent-X system. It can be connected to the main controller with a standard RJ12 cable. Multiple units can be connected into one system for multiple monitoring applications. The pH level, EC level and water temperature will be displayed on its LCD screen and the master controller screen. Features: LCD Display for onsite monitoring  RJ12 connection for flexible installation  Addressing key for multiple units application

Read more less

The optional Smoke Detector (MBS-SD) can alert the user to smoke within their growing area at ALL TIMES. Up to 5 smoke detectors can be connected to a single Hydro-x controller. If ANY of the smoke detectors determine there is smoke in the area, the user will receive a user-alert on their phone to alert them to the potential problem BEFORE the problem gets out of hand. "Sensors should remain dry and clean to prevent premature failure. Do not spray foreign substances or allow water / condensate on the sensors" Features: Small Button for Address Assignment Built-In  Photocell Detecting Day/Night Mode Plug & Play

Read more less

The Trolmaster TSH-1 Temperature / Humidity Station is a 0-10 volt analog output control station that works with the HCS-1, HCS-2 and HCS-3 controllers. The TSH-1 can be configured to control either a temperature or a humidity device that requires a variable 0-10 volt input signal. The TSH-1 is capable of controlling variable speed fans, vents or any other device that accepts a 0-10 volt input. It features separate day and night “idle” speed settings built-into the TSH-1 as well as separate Day / Night setpoints accessed through the HCS controller. FEATURES: LCD Display, Easy Operation Seamless Connection with Hydro-X, Hydro-X Pro and Hydro-X Plus Micro-SD Slot for Firmware Upgrade Assignable control of Humidity or Temperature Plug & Play

Read more less

TrolMaster's Tent-X (TCS-1) is a state-of-the-art professional-grade and modularly designed environmental and irrigation control system, designed for single-zone grow tents. Thanks to the controller's compact hydroponic capabilities, it allows the user to effectively control their tent's environmental parameters and irrigation schedule with a single control system. It comes with a 3-in-1 temperature, humidity, and light sensor, the MBS-TH. Users can daisy-chain the MBS-TH sensor with the CO2 sensor (MBS-S8), the full spectrum quantum sensor (MBS-PAR), and the smoke and water detectors into the TCS-1's SENSOR port. Users can also connect an AMP-3 sensor board to the Tent-X, and connect the Water content sensors (WCS-1/2) or the WD-1 water detector to the sensor board. Additionally, the TCS-1 supports the connection of up to four DS-type plug-in control models, allowing you to connect devices that can control the environment and irrigation. The TCS-1 is the brain that unites all your climate control and irrigation devices into one being, allowing your devices to work together to create the optimal growth environment for your plants. Features: Grow Tent Grow Lights Climate Irrigation Compact Hydroponic Control System Modular Design & Fully Customizable Smartphone Control Complete Controlled Device Capacity Data Logging

Read more less

The TS-2 thermostat stations is designed to replace a thermostat connected to a standard HVAC unit. The TS-2 can be used to control most HVAC systems including heat pump and multi-stage HVAC systems. The  TS-2 is wired to the HVAC system using the same low-voltage thermostat cable, and has the standard color-coded wiring as most thermostats. The Hydro-x allows separate Day and Night settings for each of up to (4) TS  modules, so multiple HVAC systems can be controlled by a single Hydro-X system. The TS-2 also has an adjustable delay time for each HVAC systems being activated. That minimizes high start-up (inrush current) and allows up to 4 HVAC systems to be safely controlled. FEATURES: LCD Display, Easy Operation Seamless Connection with Hydro-X Micro-SD for Firmware Upgrade Address Assignment Plug & Play

Read more less

The TS-1 thermostat stations is designed to replace a thermostat connected to a conventional cool only HVAC unit. The TS-1 is wired to the HVAC system using the same low-voltage thermostat cable, and has the standard color-coded wiring as most thermostats. The Hydro-x allows separate Day and Night settings for each of up to (4) TS  modules so multiple HVAC systems can be controlled by a single Hydro-X system.  FEATURES: LCD Display, Easy Operation Seamless Connection with Hydro-X Micro-SD for Firmware Upgrade Address Assignment Plug & Play

Read more less

The TrolMaster WCS-3 Water Content Sensor 3 is specifically designed to measure the moisture level (in percentage) of the grow medium. The WCS-3 can be used with the TrolMaster Aqua-X (NFS-1), Aqua-X Plus (NFS-3), Aqua-X Pro (NFS-2), Hydro-X Pro (HCS-2) and Tent-X (TCS-1) control systems. Each WCS-3 sensor is a 3-prong Volumetric Water Content (VWC) sensor. To use the W CS-3, you will insert the 3-prong sensor into the grow medium such as coir , soil or rock wool to be measured. You can connect multiple Medium Moisture Sensors to a single controller. Up to 5 0 WCS-3 can be connected to the NFS-2 and HCS-2 controllers, 20 o n the NFS-3, 8 on the NFS-1 controller, and 1 o n the TCS-1 controller.  *NOTE: The TCS-1 can only have a single WCS-3 connected. Each WCS-3 features a built-in LCD display on one side of the sensor that becomes “live” and can be viewed when the sensor is shaken or disturbed. The display will show the current VWC% reading right on the sensor.

Read more less

The WCS-1 water content sensor allows the user to monitor the % of water / nutrients within the growing medium. The moisture level / water content is displayed in real-time on the WCS module itself, the Aqua-x and the APP. That data is displayed on a graph (through the APP) and helps the user visualize the dry-down time, and to make adjustments to their irrigation timers / irrigation cycles. Up to 8 WCS-1 can be connected to a single Aqua-x. When multiple WCS-1 are connected to a single Aqua-X, the displayed value on the Aqua-x and APP will be the AVERAGE of all of the sensors. FEATURES: LCD Display, Easy Operation Addressing Button Water Content Real-time Measuring  Alarm When Setpoint Exceeded

Read more less

The BM-1 Weatherproof Box is designed for the protection for TrolMaster TS-1/2, HS-1 and ARS-1 controllers from dripping water and low-pressure sprayed water.

Read more less

The Vitopod Heated Propagator is the perfect solution to start your growing journey from seed. Do you have trouble getting your seeds to germinate and emerge, with them ending up looking unhealthy? Thanks to the Vitopod, this is a problem of the past. This propagator is referred to as the 'Rolls Royce of Propagators' as it delivers precision temperature control, even heat, humidity control, plenty of growing space, height adjustable layers and optional lights, giving your seeds the absolute best chance of success! Available in two sizes (Small: 60cm and Large: 111cm) and height options by way of height extension kits that can be added at any time to accommodate your taller plants. Why Choose The Vitopod? Our Vitopod Heated propagator has won many awards including - BBC Gardeners World 'Best Buy' and - Grow Your Own magazine 'Most Innovative Product' because it provides the perfect environment for seeds, cuttings and over-wintered plants. Spacious - The Large (100 watt) Vitopod fits 12x half seed trays or 55 pots! The Small (50 watt) fits 6 half seed trays or 25 seed pots. This means you can grow more varieties of your favourite plants! Precise control - the Vitopod's digital thermostat can be set to any 1°C between 5°C and 30°C to meet the exact needs of your plants. This means that you grow your seedlings in the ideal growing conditions that they need which increases the speed and strength of your germination so that you can transplant them quicker! Height adjustable - the Vitopod is bought as single layer unit and height extension kits can then be bought at any time.? Each extension increases the units height by 15cm (6in), this means that you can protect your taller plants without heating your entire greenhouse. It effectively turns into a mini greenhouse! Even heat - heat is distributed evenly throughout the base, so there are no hot or cold spots. This means that your seedlings grow more evenly with a high germination success rate. Even heat for your seedlings means it's easier to manage your watering, so that you can prevent them from drying out. Accurate soil temperature sensor - triggers the supply of heat depending on the sensor reading. This is a soil probe which is inserted into the compost/soil or the base of your propagator. This means you can maintain the right temperature without wasting electricity. Large vents - the vents in the lid allow condensation to be released preventing dampening-off without having to remove the lid. The lids help retain moisture for your seedlings which helps speedy and healthy germination, but the addition of the vents mean that you can control the humidity of your seedlings to their preference, providing excellent air circulation. Robust - this electric propagator has lids and sides which are treated to prevent yellowing. Not only this but the unit is made from the same durable, UV resistant acrylic material as aircraft windscreens! This means you can be sure that it lasts a lifetime and serves you with the same quality growing season! Also, our units are made from recycled plastic, so that you can be sure you be sure you are helping the environment whilst growing.
